Weatherproof Smart Control for Outdoor Festivities.
High/Low Voltage, Full-Protocol Outdoor Waterproof Controllers, TÜV and UL Certified.
| Input signal: | Bluetooth 5.2 SIG Mesh |
| Input Voltage: | 100-240V~ |
| Input current: | Max. 6.4A |
| Output Voltage: | 4x(100-240)V⎓ |
| Output Current: | 4CHx1.6A Max.6.4A |
| Output Power: | 4CHx(0-160...384)W Max. 1536W |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight(G.W.): | 670g |
| Waterproof rating: | IP67 |
| Protection: | Short-circuit, over-temperature, and over-current protection |
| Input signal: | DALI-2 |
| Input Voltage: | 100-240V~ |
| Input current: | Max. 6.4A |
| Output Voltage: | 4x(100-240)V⎓ |
| Output Current: | 4CHx1.6A Max.6.4A |
| Output Power: | 4CHx(0-160...384)W Max. 1536W |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L164×W70×H36(mm) |
| Package Size: | L230×W95×H47(mm) |
| Weight(G.W.): | 670g |
| Waterproof rating: | IP67 |
| Protection: | Short-circuit, over-temperature, and over-current protection |
| Input signal: | 0/1-10V |
| Input Voltage: | 100-240V~ |
| Input current: | Max. 6.4A |
| Output Voltage: | 4x(100-240)V⎓ |
| Output Current: | 4CHx1.6A Max.6.4A |
| Output Power: | 4CHx(0-160...384)W Max. 1536W |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight(G.W.): | 670g |
| Waterproof rating: | IP67 |
| Protection: | Short-circuit, over-temperature, and over-current protection |
| Input signal: | DALI-2 |
| Input Voltage: | 12-48V⎓ |
| Input current: | Max. 20.5A |
| Output Voltage: | 4x(12-48)V⎓ |
| Output Current: | 2x(4CHx2.5A) Max.20A |
| Output Power: | 4CHx(0-60...240)W Max. 960W |
| Working Temp.: | -20°C~50°C |
| Dimensions: | L164×W70×H36(mm) |
| Package Size: | L230×W95×H47(mm) |
| Weight(G.W.): | 670g |
| Waterproof rating: | IP67 |
| Protection: | Short-circuit, over-temperature and over-current protection with automatic reset capability |
| Input signal: | 0/1-10V |
| Input Voltage: | 12-48V⎓ |
| Input current: | Max. 20.5A |
| Output Voltage: | 4x(12-48)V⎓ |
| Output Current: | 2x(4CHx2.5A) Max.20A |
| Output Power: | 4CHx(0-60...240)W Max. 960W |
| Working Temp.: | -20°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight(G.W.): | 670g |
| Waterproof rating: | IP67 |
| Protection: | Short-circuit, over-temperature and over-current protection with automatic reset capability |
| Input signal: | DMX512, RDM |
| Input Voltage: | 100-240V~ |
| Input current: | Max. 6.4A |
| Output Voltage: | 4x(100-240)V⎓ |
| Output Current: | 4CHx1.6A Max.6.4A |
| Output Power: | 4CHx(0-160...384)W Max. 1536W |
| Working Temp.: | -25°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight(G.W.): | 670g |
| Waterproof rating: | IP67 |
| Protection: | Short-circuit, over-temperature, and over-current protection |
| Input signal: | DMX512, RDM |
| Input Voltage: | 12-48V⎓ |
| Input current: | Max. 20.5A |
| Output Voltage: | 4x(12-48)V⎓ |
| Output Current: | 2x(4CHx2.5A) Max.20A |
| Output Power: | 4CHx(0-60...240)W Max. 960W |
| Working Temp.: | -20°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight(G.W.): | 670g |
| Waterproof rating: | IP67 |
| Protection: | Short-circuit, over-temperature and over-current protection with automatic reset capability |
![[field:title/]](/images/pdf.jpg "4CH NFC Waterproof Bluetooth5.2 High-voltage LED Controller HB4 Manual"){kind=small}
