Utilizing RF 2.4GHz wireless transmission technology, it provides functions including On/Off control, dimming, Color Temperature (CCT) adjustment, static RGB color selection, dynamic mode effects, and scene recall, meeting user demands for diverse lighting applications.
| Input signal: | Bluetooth 5.2 SIG Mesh |
| Input Voltage: | 100-240V~ |
| Input current: | Max. 6.4A |
| Output Voltage: | 4x(100-240)V⎓ |
| Output Current: | 4CHx1.6A Max.6.4A |
| Output Power: | 4CHx(0-160...384)W Max. 1536W |
| Working Temp. | -25°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight (G.W) | 670g |
| Waterproof rating: | IP67 |
| Protect: | Short-circuit, over-temperature, and over-current protection |
| Input Voltage: | 12-24VDC, Powered by Class 2 Power Supply |
| Wireless Type: | Bluetooth 5.0 SlG Mesh |
| Compatible Devices: | B5-3A, Bluetooth Driver, Bluetooth Controller |
| Number of Scene: | 8 |
| Working Temperature: | -25°C~50°C |
| Dimensions (L×W×H): | L120xW75xH30(mm) |
| Package size (L×W×H): | L158xW113xH62(mm) |
| Weight(G.W.): | 225g |
| Control mode | RGBWY |
| Input voltage | 12-24VDC, Powered by Class 2 |
| Wireless protocol type | Bluetooth 5.0 Mesh |
| Output signals | DMX 512 |
| Zones | 4 |
| Dimensions (L×W×H) | 120×75×30(mm) |
| Package size (L×W×H) | 153×107×55(mm) |
| Weight(G.W.) | 225g |
| Control mode: | RGBW |
| Input voltage: | 12-24VDC, Powered by Class 2 |
| Wireless protocol type: | Bluetooth 5.0 Mesh |
| Output signals: | DMX 512 |
| Zones: | 4 |
| Dimensions (L×W×H): | 120×75×30(mm) |
| Package size (L×W×H): | 153×107×55(mm) |
| Weight(G.W.): | 225g |
| Control mode: | CT |
| Input voltage: | 12-24VDC, Powered by Class 2 |
| Wireless protocol type: | Bluetooth 5.0 Mesh |
| Output signals: | DMX 512 |
| Zones: | 4 |
| Dimensions (L×W×H): | 120×75×30(mm) |
| Package size (L×W×H): | 153×107×55(mm) |
| Weight(G.W.): | 225g |
| Control mode: | DIM |
| Input voltage: | 12-24VDC, Powered by Class 2 |
| Wireless protocol type: | Bluetooth 5.0 Mesh |
| Output signals: | DMX 512 |
| Zones: | 4 |
| Dimensions (L×W×H): | 120×75×30(mm) |
| Package size (L×W×H): | 153×107×55(mm) |
| Weight(G.W.): | 225g |
| Dimming mode: | RGBCW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery Cr2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30℃～55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | RGBW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery Cr2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30℃～55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | RGB |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery Cr2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30℃～55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | CT |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery Cr2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30℃～55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | DIM |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery Cr2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30℃～55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <1uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | DIM |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | CT |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | RGBW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | RGBCW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | DIM |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | CT |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | RGBW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | RGBCW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 11A |
| Load Power: | 132W@12V 240W@24V 288W@36V 384W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 12A |
| Load Power: | 144W@12V 240W@24V 288W@36V 384W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 15A |
| Load Power: | 180W@12V 360W@24V 432W@36V 432W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 15A |
| Load Power: | 180W@12V 288W@24V 360W@36V 480W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 15A |
| Load Power: | 180W@12V 360W@24V 450W@36V 600W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input signal: | Bluetooth 5.2 SIG Mesh |
| Input voltage: | 12-24V |
| Output voltage: | 12-24V |
| Load current: | 3Ax5CH Max.15A |
| Load power: | 180W@12V 360W@24V |
| Protection: | Short circuit, over-temperature, over-current protection, anti-reverse connection protection |
| Operating temperature: | -25°C ~ 50°C |
| Dimensions: | L91xW37xH21(mm) |
| Package Size: | L94xW39xH22(mm) |
| Weight (G.W): | 46g |
