DALI+ Bluetooth Dual-Function Dimming Controller and Accessories empower you to efficiently manage five control types: DALI dimming, color temperature, RGB, RGBW, and RGBCW. Featuring NFC programming support, it enables NFC-based configuration of DALI addresses, DALI groups, DALI scenes, and broadcast mode.
| Output signal: | DALI-2 |
| Input voltage: | 100-240V~,50/60Hz, μ |
| Channels: | 4 |
| Load Current: | 12A/CH |
| Load Parameters: | Resistive load: 2760W@230V~/CH，1320W@110V~/CH Capacitive load: 1380W@230V~/CH，660W@110V~/CH |
| Switching Voltage: | 250V~ |
| Inrush Current in Loads: | 70A@10ms |
| Working Temperature: | -25°C ~ 50°C |
| Dimension: | L91.5×W54×H59(mm) |
| Package Size: | L94×W55×H60(mm) |
| Weight (G.W): | 46g |
| Input signal: | DALI-2 |
| Operating Voltage: | 100-240Vac , 50/60Hz μ |
| Output Signal: | Relay |
| Switching Voltage: | 100-240Vac |
| Maximum load current: | 8A |
| Load parameters: | Resistive load: 1200W@230Vac，600W@110Vac Capacitive load: 600W@230Vac，300W@110Vac |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Peak current: | 30mA@16V |
| Static current: | 2.5mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | DALI-2 |
| Output Method: | Relay |
| Load parameters: | Resistiveload: 800W@230Vac,400W@110Vac，200W@48Vdc; Capacitive load: 300w@230Vac, 150W@110Vac，100W@48Vdc |
| Switch maximum voltage: | Max.250Vac，Max.48Vdc |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Peak current: | 30mA@16V |
| Static current: | 2.5mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | DALI-2 |
| Output Method: | Relay |
| Load parameters: | Resistiveload: 800W@230Vac,400W@110Vac，200W@48Vdc; Capacitive load: 300w@230Vac, 150W@110Vac，100W@48Vdc |
| Switch maximum voltage: | AC: 250V，DC: 48V |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Output Signal: | DALI |
| Bus Power Current: | 200mA@16V |
| Rated Parameters: | 100-240V~，50/60Hz |
| Control Type: | DIM, CT, RGB, RGBW, RGBCW |
| Wireless Type: | Bluetooth 5.0 SIG Mesh |
| Compatible remote: | B1、B2、B5、B8、RC4-BLE |
| Compatible APP: | L-Home、 NFC Lighting |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 86x86x52mm(LxWxH) |
| Package Size: | 102x102x73mm(LxWxH) |
| Weight: | 130g |
| Peak current: | 70mA@16V |
| Static current: | 5mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | DALI-2 |
| Output signal: | 0/1-10V×2CH，Max.15mA |
| Load parameters: | Resistive load: 800W@230Vac，400W@110Vac，200W@48Vdc Capacitive load: 300W@230Vac，150W@110Vac，100W@48Vdc |
| Switch maximum voltage: | Max.250Vac，Max.48Vdc |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Peak current: | 70mA@16V |
| Static current: | 5mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | DALI-2 |
| Output signal: | 0/1-10V×2CH，Max.15mA |
| Load parameters: | Resistive load: 800W@230Vac，400W@110Vac，200W@48Vdc Capacitive load: 300W@230Vac，150W@110Vac，100W@48Vdc |
| Switch maximum voltage: | Max.250Vac，Max.48Vdc |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Interface protocols: | DALI-2 DT6 |
| Operating voltage: | 100-240V~,50/60Hz |
| Input signal: | DALI |
| Output signal: | Triac/ELV |
| Load parameters: | Incandescent lamps or high-pressure halogen lamps: Max.400W@220Vac, Max.200W@110Vac. Dimmable LEDs: Max.200W@220Vac, Max.100W@110Vac |
| Load inrush current: | Max.60A |
| Working environment: | -20°C~50°C |
| Product size: | L45xW20.5xH45.5(mm) |
| Package size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Current consumption: | ≤2mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | Dry contact |
| Output signal: | DALI |
| Working environment: | -25°C~50°C |
| Product size: | L45xW20.5xH45.5(mm) |
| Package size: | L50xW28xH50(mm) |
| Product weight: | 30g |
| Wireless Protocol Type: | Bluetooth 5.0 SIG Mesh |
| Output Signal: | DALI |
| Input Voltage: | 12-22.5Vdc |
| Number of addresses: | 64 |
| Working Temperature: | -20°C~55°C |
| Product Size(L×W×H): | 52×59×20(mm) |
| Package Size(L×W×H): | 86×86×25(mm) |
| Weight(G. W.): | 40g |
| Wireless Protocol Type: | Bluetooth 5.0 SIG Mesh |
| Output Signal: | DALI |
| Input Voltage: | 9.5-22.5Vdc |
| Working Temperature: | -20°C~55°C |
| Product Size(L×W×H): | 52×59×20(mm) |
| Package Size(L×W×H): | 86×86×25(mm) |
| Weight(G. W.): | 40g |
| Wireless protocol: | Bluetooth5.0 SIG Mesh |
| Power voltage: | 120-277Vac,50/60Hz |
| Load power: | 400VA(Capacitive load),800W(Resistive load) |
| Microwave frequency: | 10.525GHz |
| Emission frequency: | 2dB |
| Stand-by power consumption: | ≤1W |
| Ceiling height: | ≤3.3m |
| Detection range: | ≤6m |
| IP rating: | IP20 |
| Dimensions: | 83*83*72mm(LxWxH) |
| Power voltage: | DALI |
| Microwave frequency: | 5.8GHz±75MHz |
| Emission frequency: | ≤0.5mW |
| Stand-by power consumption: | ≤0.5W |
| Ceiling height: | ≤6m |
| Detection range: | ≤10m |
| IP rating: | IP20 |
| Dimensions: | 95*45*26.5mm(LxWxH) |
| Output signal: | DALI-2 |
| Input voltage: | 100-240V~ |
| Capacitive load: | 2200W@230V~，1100W@110V~ |
| Resistive load: | 1000W@230V~，500W@110V~ |
| Maximum current: | 12A |
| frequency: | 50/60Hz |
| Working Temperature: | -20℃-55℃ |
| Dimension: | L112×W35×H67mm |
| Package Size: | L114×W37×H69mm |
| Weight (G.W): | 109g |
| Output signal: | DALI |
| Power Supply: | DALI power |
| Dimming key: | RGBW control |
| Power consumption: | < 6mA@16V |
| working temperature: | -30 ~55 ℃ |
| Dimension: | L86×W86×H37(mm) |
| Package Size: | L113×W112×H50(mm) |
| Weight (G.W): | 240g |
| Input signal: | DALI DT6/DT8, Push DIM (Extended mode only) |
| Input voltage: | 100-240Vac |
| Rated DALI input current: | <2mA |
| Output signal: | DALI DT6/DT8 |
| Rated DALI output current: | Max. 220mA |
| Mounting: | Din Rail or Screw |
| Dimension: | L112×W35×H67(mm) |
| Package Size: | L114×W37×H70(mm) |
| Weight (G.W): | 130g |
| Dimming interface: | DMX/RDM,DALI,Push Dim |
| Output signal: | 0-10V×4CH |
| Output signal logic: | High potential |
| Input voltage: | 100-240Vac/277Vac (277 Vac for North America only) |
| Dimming range: | 0～100% |
| Dimensions: | 175×44×30mm(L×W×H) |
| Pacakge size: | 178×48×33mm(L×W×H) |
| Weight (G.W): | 110g±10g |
| Input Voltage: | 100~240Vac, 50~60Hz |
| Input signal: | DALI, DMX/RDM, PUSH |
| Output: | Max. 5A/100V~; Max. 2A/240V~ |
| Dimming Mode: | Leading edge (triac) |
| working temperature: | -30℃~55℃ |
| Dimension: | L175×W44×H30(mm) |
| Package Size: | L178×W48×H33(mm) |
| Weight (G.W): | 140g |
| Output signal: | DALI |
| Power Supply: | DALI power |
| Dimming key: | RGB control |
| Power consumption: | < 6mA@16V |
| working temperature: | -30 ~55 ℃ |
| Dimension: | L86×W86×H37(mm) |
| Package Size: | L113×W112×H50(mm) |
| Weight (G.W): | 240g |
| Output signal: | DALI |
| Power Supply: | DALI power |
| Dimming key: | CT control |
| Power consumption: | < 6mA@16V |
| working temperature: | -30 ~55 ℃ |
| Dimension: | L86×W86×H37(mm) |
| Package Size: | L113×W112×H50(mm) |
| Weight (G.W): | 240g |
| Output signal: | DALI |
| Power Supply: | DALI power |
| Dimming key: | Dimming control |
| Power consumption: | < 6mA@16V |
| working temperature: | -30 ~55 ℃ |
| Dimension: | L86×W86×H37(mm) |
| Package Size: | L113×W112×H50(mm) |
| Weight (G.W): | 240g |
| Interface Protocol: | DALI (IEC62386) |
| Power supply: | DALI bus |
| Signal current: | ≤8mA (static) |
| Work temp.: | -30℃~ 55℃ |
| Dimension: | L48×W28×H14(mm) |
| Package size: | L50×W40×H30(mm) |
| Weight (G.W.): | 32g |
| Power supply: | DALI power |
| Output signal: | DALI |
| Dimming style: | Spin |
| Static current: | 6mA@16V |
| Standby current: | 4mA@16V |
| Working temperature: | -10℃~55℃ |
| Dimensions: | L86×W86×H50(mm) |
| Package Size: | L106×W106×H60(mm) |
| Weight(G.W.): | 235g |
| Input Voltage: | 100-240VAC 50/60Hz |
| Input Current: | 115VAC/≤0.09A 230VAC/≤0.05A |
| Out Current: | 200mA |
| Work Current: | 15V |
| working temperature: | -30℃～55℃ |
| Dimension: | L112×W35×H67(mm) |
| Package Size: | L114×W37×H70(mm) |
| Weight (G.W): | 115g±10g |
| Output signal: | DALI |
| Power Supply: | DALI power |
| Dimming key: | 1CH control |
| Static current: | 6mA@16V |
| Standby current: | 4mA@16V |
| working temperature: | -30 ~55 ℃ |
| Dimension: | L86×W86×H37(mm) |
| Package Size: | L113×W112×H50(mm) |
| Weight (G.W): | 200g |
| Output signal: | DALI |
| Power Supply: | DALI power |
| Dimming key: | 2CH control |
| Static current: | 6mA@16V |
| Standby current: | 4mA@16V |
| working temperature: | -30 ~55 ℃ |
| Dimension: | L86×W86×H37(mm) |
| Package Size: | L113×W112×H50(mm) |
| Weight (G.W): | 200g |
| Output signal: | DALI |
| Power Supply: | DALI power |
| Dimming key: | 3CH control |
| Static current: | 6mA@16V |
| Standby current: | 4mA@16V |
| working temperature: | -30 ~55 ℃ |
| Dimension: | L86×W86×H37(mm) |
| Package Size: | L113×W112×H50(mm) |
| Weight (G.W): | 200g |
| Output signal: | DALI |
| Power Supply: | DALI power |
| Dimming key: | 4CH control |
| Static current: | 6mA@16V |
| Standby current: | 4mA@16V |
| working temperature: | -30 ~55 ℃ |
| Dimension: | L86×W86×H37(mm) |
| Package Size: | L113×W112×H50(mm) |
| Weight (G.W): | 200g |
