The MINI Series LED Remote Control utilizes RF 2.4GHz wireless transmission technology, When paired with the P5 controller, a single controller supports 5 outputs and is compatible with five lighting types: DIM, CT, RGB, RGBW, and RGBCW. Within its effective range, one remote can control multiple controllers, enabling functions such as lighting on/off, brightness adjustment, color temperature tuning, RGB static colors, dynamic mode effects, and scene recall. This meets diverse lighting application needs.
| Dimming mode: | RGBCW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery Cr2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30℃~55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | RGBW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery Cr2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30℃~55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | RGB |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery Cr2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30℃~55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | CT |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery Cr2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30℃~55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Dimming mode: | DIM |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button battery Cr2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30℃~55℃ |
| Weight: | 86g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <1uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | DIM |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | CT |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | RGBW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | RGBCW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | DIM |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | CT |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | RGBW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Color: | White/Black |
| Dimming mode: | RGBCW |
| Wireless protocol: | RF 2.4GHz |
| Working voltage: | 3Vdc (Button cell CR2032×1) |
| Standby current: | <2uA |
| Distance of remote: | 30M (Under no interference) |
| Working temp.: | -30°C~55°C |
| Weight: | 40g±10g |
| Dimensions: | 104×58×9mm (Remote), 108×63×14mm (Remote + Holder) |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 11A |
| Load Power: | 132W@12V 240W@24V 288W@36V 384W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 12A |
| Load Power: | 144W@12V 240W@24V 288W@36V 384W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 15A |
| Load Power: | 180W@12V 360W@24V 432W@36V 432W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 15A |
| Load Power: | 180W@12V 288W@24V 360W@36V 480W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
| Input Signal: | RF2.4GHz |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | Max. 15A |
| Load Power: | 180W@12V 360W@24V 450W@36V 600W@48V |
| Protection: | Over Temperature Protection, Anti Reverse Connection Protection |
| Working Temp.: | -25°C ~ 50°C |
| Dimension: | L91×W37×H21(mm) |
| Package Size: | L94×W39×H22(mm) |
| Weight(G.W.): | 46g |
