Aligned with the requirements for dimming, color temperature adjustment, and RGBCW color light control, it supports a wide-gamut and wide-color-temperature adjustable spectral algorithm for RGBCW. Through APP settings and association with the super panel, simultaneous control by both the APP and the panel can be achieved. Moreover, via panel networking, remote control of the driver through the APP, cloud scenes, and automated linkage functions are enabled. It realizes ultra-human-centric adaptive intelligent lighting technology and supports customized full-circadian natural light and all-environment natural light.
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| DC Voltage Range: | 200-280Vdc |
| AC Voltage Range: | 220-240Vac |
| Input Voltage: | 230Vac |
| Power Factor: | PF>0.95/230Vac (at full load) |
| Efficiency: | 88% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 1.5A |
| Output Power: | Max. 36W |
| Dimming Range: | 0~100%, down to 0.0001% |
| Certification: | CCC,TUV,CB,CE,EAC,RCM,ENEC,UKCA,ERP,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| DC Voltage Range: | 200-280Vdc |
| AC Voltage Range: | 220-240Vac |
| Input Voltage: | 230Vac |
| Power Factor: | PF>0.95/230Vac (at full load) |
| Efficiency: | 88% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 1.5A |
| Output Power: | Max. 36W |
| Dimming Range: | 0~100%, down to 0.0001% |
| Certification: | CCC,TUV,CB,CE,EAC,RCM,ENEC,UKCA,ERP,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| DC Voltage Range: | 220-240V |
| AC Voltage Range: | 220-240Vac |
| Power Factor: | PF>0.98/230V (at full load) |
| Efficiency: | 92% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 3.125A |
| Output Power: | 0~75W |
| Dimming Range: | 0~100%, down to 0.0001% |
| Certification: | CCC,TUV,CB,CE,EAC,RCM,ENEC,ERP,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| DC Voltage Range: | 220-240V |
| AC Voltage Range: | 220-240Vac |
| Power Factor: | PF>0.98/230V (at full load) |
| Efficiency: | 92% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 3.125A |
| Output Power: | 0~75W |
| Dimming Range: | 0~100%, down to 0.0001% |
| Certification: | CCC,TUV,CB,CE,EAC,RCM,ENEC,ERP,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| DC Voltage Range: | 220-240V |
| AC Voltage Range: | 220-240Vac |
| Power Factor: | PF>0.98/230V (at full load) |
| Efficiency: | 93% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 6.25A |
| Output Power: | 0~150W |
| Dimming Range: | 0~100%, down to 0.0001% |
| Certification: | CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,ERP,BIS,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| DC Voltage Range: | 220-240V |
| AC Voltage Range: | 220-240Vac |
| Power Factor: | PF>0.98/230V (at full load) |
| Efficiency: | 93% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 6.25A |
| Output Power: | 0~150W |
| Dimming Range: | 0~100%, down to 0.0001% |
| Certification: | CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,ERP,BIS,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| DC Voltage Range: | 200-280Vdc |
| AC Voltage Range: | 198-264Vac |
| Power Factor: | PF>0.98/230Vac (at full load) |
| Efficiency: | 93% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 6.25A (1.56Ax4CH) |
| Output Power: | 0~150W |
| Dimming Range: | 0~100%, down to 0.0001% |
| Certification: | CCC,CE,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| DC Voltage Range: | 200-250Vdc |
| AC Voltage Range: | 220-240Vac |
| Input Voltage: | 220-240Vac |
| Power Factor: | PF>0.99/230Vac, at full load |
| Efficiency: | 94% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 10A |
| Output Power: | 0~240W |
| Dimming Range: | 0~100%, down to 0.0001% |
| Certification: | CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,ERP,BIS,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| DC Voltage Range: | 200-250Vdc |
| AC Voltage Range: | 220-240Vac |
| Input Voltage: | 220-240Vac |
| Power Factor: | PF>0.99/230Vac, at full load |
| Efficiency: | 94% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 10A |
| Output Power: | 0~240W |
| Dimming Range: | 0~100%, down to 0.0001% |
| Certification: | CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,ERP,BIS,ROHS |
| Warranty: | 5 years |
| Chemi-Con capacitors | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| Input Voltage: | 100-277V~ |
| Power Factor: | PF>0.95/100V~, PF>0.95/230V~, PF>0.85/277V~(at full load) |
| Efficiency: | 84%/100V~, 90%/230V~, 90%/277V~ |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 2.5A |
| Output Power: | 0-60W |
| Dimming Range: | 0~100%, dimming down to 0.0001% |
| Certification: | UL,CUL,CE,FCC,ROHS |
| Warranty: | 5 years |
| Chemi-Con capacitors | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| Input Voltage: | 100-277V~ |
| Power Factor: | PF>0.95/100V~, PF>0.95/230V~, PF>0.9/277V~(at full load) |
| Efficiency: | 85%/100V~, 91%/230V~, 91%/277V~ |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 4.0A |
| Output Power: | 0~96W |
| Dimming Range: | 0~100%, dimming down to 0.0001% |
| Certification: | UL,CUL,CE,FCC,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| Input Voltage: | 120-277Vac |
| Power Factor: | PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load) |
| Efficiency: | 91% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 2.5A |
| Output Power: | 0-60W |
| Dimming Range: | 0~100%, down to 0.1% |
| Certification: | FCC,CE,UL,CUL,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| Input Voltage: | 120-277Vac |
| Power Factor: | PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load) |
| Efficiency: | 91% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 2.5A |
| Output Power: | 0-60W |
| Dimming Range: | 0~100%, down to 0.1% |
| Certification: | FCC,CE,UL,CUL,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| Input Voltage: | 120-277Vac |
| Power Factor: | PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load) |
| Efficiency: | 93% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 4.13A |
| Output Power: | 0-100W |
| Dimming Range: | 0~100%, down to 0.1% |
| Certification: | FCC,CE,ROHS,UL,CUL |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Bluetooth 5.0 SIG Mesh |
| Input Voltage: | 120-277Vac |
| Power Factor: | PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load) |
| Efficiency: | 93% |
| Fluctuation Level: | High frequency exemption level. |
| Output Voltage: | 24Vdc |
| Output Current: | Max. 4.13A |
| Output Power: | 0-100W |
| Dimming Range: | 0~100%, down to 0.1% |
| Certification: | FCC,CE,ROHS,UL,CUL |
| Warranty: | 5 years |
