中文 | Stock Code:
920110
The Matter Constant Current smart LED driver meets diverse lighting control needs, including dimming, color temperature adjustment, and color control (RGBCW). It also features LTECH’s NFC programmable technology, allowing parameters such as switch dimming fade time, power-on fade time, and brightness range to be edited via a mobile app. Multi-device setup is effortless, greatly improving engineering and maintenance efficiency.
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| AC Voltage Range: | 100-277V~ |
| Input Voltage: | 115V~/230V~/277V~ |
| Power Factor: | PF≥0.95/115V~, PF≥0.9/230V~, PF≥0.85/277V~(at full load) |
| Efficiency: | 80%(at full load) |
| Fluctuation Level: | High frequency exemption assessment level. |
| Output Voltage: | 9-42V |
| Output Current: | 100-450mA |
| Output Power: | 0.9-10W |
| Dimming Range: | 0-100%, down to 0.0001% |
| Certification: | UL,CUL,FCC,CE,ROHS |
| Warranty: | 5 years |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| AC Voltage Range: | 100-277V~ |
| Input Voltage: | 115V~/230V~/277V~ |
| Power Factor: | PF≥0.95/115V~, PF≥0.9/230V~, PF≥0.9/277V~(at full load) |
| Efficiency: | 84%(at full load) |
| Fluctuation Level: | High frequency exemption assessment level. |
| Output Voltage: | 9-42V |
| Output Current: | 100-700mA |
| Output Power: | 0.9-20W |
| Dimming Range: | 0-100%, down to 0.0001% |
| Certification: | UL,CUL,FCC,CE,ROHS |
| Warranty: | 5 years |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| AC Voltage Range: | 100-277V~ |
| Input Voltage: | 115V~/230V~/277V~ |
| Power Factor: | PF≥0.95/115V~, PF≥0.9/230V~, PF≥0.9/277V~(at full load) |
| Efficiency: | 86%(at full load) |
| Fluctuation Level: | High frequency exemption assessment level. |
| Output Voltage: | 9-42V |
| Output Current: | 200-1050mA |
| Output Power: | 1.8-30W |
| Dimming Range: | 0-100%, down to 0.0001% |
| Certification: | UL,CUL,FCC,CE,ROHS |
| Warranty: | 5 years |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| AC Voltage Range: | 100-277V~ |
| Input Voltage: | 115V~/230V~/277V~ |
| Power Factor: | PF≥0.95/115V~, PF≥0.9/230V~, PF≥0.9/277V~(at full load) |
| Efficiency: | 86%(at full load) |
| Fluctuation Level: | High frequency exemption assessment level. |
| Output Voltage: | 9-42V |
| Output Current: | 300-1200mA |
| Output Power: | 2.7-40W |
| Dimming Range: | 0-100%, down to 0.0001% |
| Certification: | UL,CUL,FCC,CE,ROHS |
| Warranty: | 5 years |
| Rubycon capacitor | |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| DC Voltage Range: | 120-250V |
| AC Voltage Range: | 100-240Vac |
| Input Voltage: | ≤0.45A/115V~, ≤0.22A/230V~ |
| Power Factor: | PF>0.95/115Vac , PF>0.90/230Vac, at full load |
| Efficiency: | 88%@950mA (Fully loaded) |
| Fluctuation Level: | No visible flicker/High frequency exemption level |
| Output Voltage: | 9-42Vdc |
| Output Current: | 300-1050mA |
| Output Power: | 2.7W~40W |
| Dimming Range: | 0-100%，Dimming depth: 0.0001% |
| Certification: | CCC,CB,CE,CUL,UL,ERP,ROHS |
| Warranty: | 5 years（Rubycon capacitor） |
| Rubycon capacitor | |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| DC Voltage Range: | 120-250V |
| AC Voltage Range: | 100-240Vac |
| Input Voltage: | ≤0.45A/115V~, ≤0.22A/230V~ |
| Power Factor: | PF>0.95/115Vac , PF>0.90/230Vac, at full load |
| Efficiency: | 88%@950mA (Fully loaded) |
| Fluctuation Level: | No visible flicker/High frequency exemption level |
| Output Voltage: | 9-42Vdc |
| Output Current: | 300-1050mA |
| Output Power: | 2.7W~40W |
| Dimming Range: | 0-100%，Dimming depth: 0.0001% |
| Certification: | CCC,CB,CE,CUL,UL,ERP,ROHS |
| Warranty: | 5 years（Rubycon capacitor） |
| Rubycon capacitor | |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| DC Voltage Range: | 120-250V |
| AC Voltage Range: | 100-240Vac |
| Input Voltage: | ≤0.34A/115V~, ≤0.17A/230V~ |
| Power Factor: | PF>0.95/115Vac , PF>0.90/230Vac, at full load |
| Efficiency: | 87%@750mA (Fully loaded) |
| Fluctuation Level: | No visible flicker/High frequency exemption level |
| Output Voltage: | 9-42Vdc |
| Output Current: | 200-800mA |
| Output Power: | 1.8W~30W |
| Dimming Range: | 0-100%，Dimming depth: 0.0001% |
| Certification: | CCC,CB,CE,CUL,UL,ERP,ROHS |
| Warranty: | 5 years（Rubycon capacitor） |
| Rubycon capacitor | |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| DC Voltage Range: | 120-250V |
| AC Voltage Range: | 100-240Vac |
| Input Voltage: | ≤0.34A/115V~, ≤0.17A/230V~ |
| Power Factor: | PF>0.95/115Vac , PF>0.90/230Vac, at full load |
| Efficiency: | 87%@750mA (Fully loaded) |
| Fluctuation Level: | No visible flicker/High frequency exemption level |
| Output Voltage: | 9-42Vdc |
| Output Current: | 200-800mA |
| Output Power: | 1.8W~30W |
| Dimming Range: | 0-100%，Dimming depth: 0.0001% |
| Certification: | CCC,CB,CE,CUL,UL,ERP,ROHS |
| Warranty: | 5 years（Rubycon capacitor） |
| Rubycon capacitor | |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| DC Voltage Range: | 100-240V |
| AC Voltage Range: | 100-240Vac |
| Input Voltage: | ≤0.25A/115V~, ≤0.13A/230V~ |
| Power Factor: | PF>0.95/115Vac , PF>0.90/230Vac, at full load |
| Efficiency: | 84%@700mA (Fully loaded) ,87%@500mA (Fully loaded) |
| Fluctuation Level: | No visible flicker/High frequency exemption level |
| Output Voltage: | 9-42Vdc |
| Output Current: | 100-700mA |
| Output Power: | 0.9W-20W |
| Dimming Range: | 0-100%，Dimming depth: 0.0001% |
| Certification: | CCC,CB,CE,CUL,UL,ERP,ROHS |
| Warranty: | 5 years（Rubycon capacitor） |
| Rubycon capacitor | |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| DC Voltage Range: | 100-240V |
| AC Voltage Range: | 100-240Vac |
| Input Voltage: | ≤0.25A/115V~, ≤0.13A/230V~ |
| Power Factor: | PF>0.95/115Vac , PF>0.90/230Vac, at full load |
| Efficiency: | 84%@700mA (Fully loaded) ,87%@500mA (Fully loaded) |
| Fluctuation Level: | No visible flicker/High frequency exemption level |
| Output Voltage: | 9-42Vdc |
| Output Current: | 100-700mA |
| Output Power: | 0.9W-20W |
| Dimming Range: | 0-100%，Dimming depth: 0.0001% |
| Certification: | CCC,CB,CE,CUL,UL,ERP,ROHS |
| Warranty: | 5 years（Rubycon capacitor） |
| Rubycon capacitor | |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| DC Voltage Range: | 100-240V |
| AC Voltage Range: | 100-240Vac |
| Input Voltage: | ≤0.18A/115V~, ≤0.08A/230V~ |
| Power Factor: | PF>0.95/115Vac , PF>0.90/230Vac, at full load |
| Efficiency: | 84%@300mA (Fully loaded) ,82%@500mA (Fully loaded) |
| Fluctuation Level: | No visible flicker/High frequency exemption level |
| Output Voltage: | 9-42Vdc |
| Output Current: | 100-500mA |
| Output Power: | 0.9W-12W |
| Dimming Range: | 0-100%，Dimming depth: 0.0001% |
| Certification: | CCC,CB,CE,CUL,UL,ERP,ROHS |
| Warranty: | 5 years（Rubycon capacitor） |
| Rubycon capacitor | |
| Dimming Interface: | Matter over Thread, Matter 1.4 |
| DC Voltage Range: | 100-240V |
| AC Voltage Range: | 100-240Vac |
| Input Voltage: | ≤0.18A/115V~, ≤0.08A/230V~ |
| Power Factor: | PF>0.95/115Vac , PF>0.90/230Vac, at full load |
| Efficiency: | 84%@300mA (Fully loaded) ,82%@500mA (Fully loaded) |
| Fluctuation Level: | No visible flicker/High frequency exemption level |
| Output Voltage: | 9-42Vdc |
| Output Current: | 100-500mA |
| Output Power: | 0.9W-12W |
| Dimming Range: | 0-100%，Dimming depth: 0.0001% |
| Certification: | CCC,CB,CE,CUL,UL,ERP,ROHS |
| Warranty: | 5 years（Rubycon capacitor） |
