Compatible with both European and Chinese standard 86mm flush-mount boxes. Product certified by TÜV. Features wired DMX512 protocol + wireless Bluetooth 5.2 protocol. Vibrant lighting effects at your fingertips! The series covers dimming, color temperature, RGB, RGBW, RGBCW, and lighting scene control, meeting diverse lighting control needs!Through the Xiaolei Super Intelligent Gateway S80, you can connect to the Apple Home ecosystem and the Matter protocol, enabling interconnection of cross-brand devices.
| Input signal: | Bluetooth 5.2 SIG Mesh |
| Input Voltage: | 100-240V~ |
| Input current: | Max. 6.4A |
| Output Voltage: | 4x(100-240)V⎓ |
| Output Current: | 4CHx1.6A Max.6.4A |
| Output Power: | 4CHx(0-160...384)W Max. 1536W |
| Working Temp. | -25°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight (G.W) | 670g |
| Waterproof rating: | IP67 |
| Protect: | Short-circuit, over-temperature, and over-current protection |
| Output Signal: | DALI |
| Bus Power Current: | 200mA@16V |
| Rated Parameters: | 100-240V~，50/60Hz |
| Control Type: | DIM, CT, RGB, RGBW, RGBCW |
| Wireless Type: | Bluetooth 5.0 SIG Mesh |
| Compatible remote: | B1、B2、B5、B8、RC4-BLE |
| Compatible APP: | L-Home、 NFC Lighting |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 86x86x52mm(LxWxH) |
| Package Size: | 102x102x73mm(LxWxH) |
| Weight: | 130g |
| Output Signal: | DMX512 |
| Rated Parameters: | 100-240V~，50/60Hz |
| Control Type: | DIM, CT, RGB, RGBW, RGBCW |
| Wireless Type: | Bluetooth 5.0 SIG Mesh |
| Compatible remote: | B1、B2、B5、B8、RC4-BLE |
| Compatible Driver: | DMX driver, DMX decoder |
| Compatible APP: | L-Home、 NFC Lighting |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 86x86x52mm(LxWxH) |
| Package Size: | 102x102x73mm(LxWxH) |
| Weight: | 130g |
| Output Signal: | 0-10V |
| Rated Parameters: | 100-240V~，50/60Hz |
| Control Type: | DIM, CT |
| Wireless Type: | Bluetooth 5.0 SIG Mesh |
| Compatible remote: | B1、B2、B8、RC4-BLE |
| Compatible Driver: | 0-10V dimming, color temperature drive |
| Compatible APP: | L-Home、 NFC Lighting |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 86x86x52mm(LxWxH) |
| Package Size: | 102x102x73mm(LxWxH) |
| Weight: | 130g |
| Output Signal: | Triac |
| Rated Parameters: | 100-240V~，50/60Hz |
| Control Type: | DIM |
| Wireless Type: | Bluetooth 5.0 SIG Mesh |
| Compatible remote: | B1、B2、B8、RC4-BLE |
| Compatible Driver: | Triac driver |
| Compatible APP: | L-Home、 NFC Lighting |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 86x86x52mm(LxWxH) |
| Package Size: | 102x102x73mm(LxWxH) |
| Weight: | 130g |
| Control Type: | DIM |
| Output Voltage: | 100-240V~ |
| Output Signal: | DMX512 |
| Wireless Type: | Bluetooth 5.2 SIG Mesh |
| Compatible Remote Control: | B1 |
| Compatible Driver: | B5-3A,DMX decoder |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 86x86x36mm(LxWxH) |
| Package Size: | 113x112x50mm(LxWxH) |
| Weight: | 155g |
| Control Type: | CT |
| Output Voltage: | 100-240V~ |
| Output Signal: | DMX512 |
| Wireless Type: | Bluetooth 5.2 SIG Mesh |
| Compatible Remote Control: | B2 |
| Compatible Driver: | B5-3A,DMX decoder |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 86x86x36mm(LxWxH) |
| Package Size: | 113x112x50mm(LxWxH) |
| Weight: | 155g |
| Control Type: | RGB/RGBW/RGBCW |
| Output Voltage: | 100-240V~ |
| Output Signal: | DMX512 |
| Wireless Type: | Bluetooth 5.2 SIG Mesh |
| Compatible Remote Control: | B5 |
| Compatible Driver: | B5-3A,DMX decoder |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 86x86x36mm(LxWxH) |
| Package Size: | 113x112x50mm(LxWxH) |
| Weight: | 155g |
| Output Voltage: | 100-240V~ |
| Control Type: | DIM,CT,RGB,RGBW,RGBCW |
| Output Signal: | DMX512.DMX decoder |
| Wireless Type: | Bluetooth 5.2 SlG Mesh |
| Compatible Driver: | B5-3A |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 86x86x50mm(LxWxH) |
| Package Size: | 105x105x63mm(LxWxH) |
| Weight: | 225g |
| Output Voltage: | 100-240V~ |
| Wireless Type: | Bluetooth 5.2 SlG Mesh |
| Compatible Driver: | B5-3A, Bluetooth drivers and Bluetooth controllers |
| Number of Scenes: | 8 scenes |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 86x86x36mm(LxWxH) |
| Package Size: | 113x112x50mm(LxWxH) |
| Weight: | 225g |
| Control Type: | DIM |
| Working Voltage: | 3Vdc(AAAx2) |
| Wireless Type: | Bluetooth 5.2 SIG Mesh |
| Number of Zones: | 4-zone control |
| Matching Touch Panel: | EB1/EB6 |
| Compatible Driver: | B5-3A |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 162x42x15mm(LxWxH) |
| Package Size: | 166x47x22mm(LxWxH) |
| Weight: | 55g±10g |
| Control Type: | CT |
| Working Voltage: | 3Vdc(AAAx2) |
| Wireless Type: | Bluetooth 5.2 SIG Mesh |
| Number of Zones: | 4-zone control |
| Matching Touch Panel: | EB2/EB6 |
| Compatible Driver: | B5-3A |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 162x42x15mm(LxWxH) |
| Package Size: | 166x47x22mm(LxWxH) |
| Weight: | 55g±10g |
| Control Type: | RGB/RGBW/RGBCW |
| Working Voltage: | 3Vdc(AAAx2) |
| Wireless Type: | Bluetooth 5.2 SIG Mesh |
| Number of Zones: | 4-zone control |
| Matching Touch Panel: | EB5/EB6 |
| Compatible Driver: | B5-3A |
| Working Temperature: | -25°C~50°C |
| Dimensions: | 162x42x15mm(LxWxH) |
| Package Size: | 166x47x22mm(LxWxH) |
| Weight: | 55g±10g |
| Control Type: | Scene Control |
| Working Voltage: | 3Vdc (1xCR2032 button battery) |
| Wireless Type: | Bluetooth 5.2 SIG Mesh |
| Compatible Driver: | B5-3A |
| Working Temperature: | -15°C~50°C |
| Dimensions: | 145x40x12mm(LxWxH) |
| Package Size: | 148.5x46x19mm(LxWxH) |
| Weight: | 50g±10g |
| Input signal: | Bluetooth 5.2 SIG Mesh |
| Input voltage: | 12-24V |
| Output voltage: | 12-24V |
| Load current: | 3Ax5CH Max.15A |
| Load power: | 180W@12V 360W@24V |
| Protection: | Short circuit, over-temperature, over-current protection, anti-reverse connection protection |
| Operating temperature: | -25°C ~ 50°C |
| Dimensions: | L91xW37xH21(mm) |
| Package Size: | L94xW39xH22(mm) |
| Weight (G.W): | 46g |
| Wireless Protocol Type: | Bluetooth 5.0 SIG Mesh,DMX/RDM |
| Output Voltage: | 5-24Vdc |
| Input Voltage Range: | 5-24Vdc |
| Load Current: | 4A×5CH / 5A×4CH Max. 20A |
| Load Power: | (0~20W...96W)×5CH Max. 480W |
| Protection: | Short circuit, overcurrent, overheat, anti-reverse protection |
| Working Temperature: | -20°C ~ 55°C |
| Dimensions: | L175×W44×H30(mm) |
| Package Size: | L178×W48×H33(mm) |
| Weight (G.W): | 130g |
