LTECH's 0-10V & 1-10V to PWM dimming drivers perfectly resolve compatibility issues between fluorescent dimming systems and LED lighting.
They allow LED lighting control via mainstream traditional dimming systems, including Lutron, Dynalite, Tridonic, Schneider, Clipsal, Osram, Philips, ABB, and others.
| Input signal: | 0/1-10V |
| Input Voltage: | 12-48V⎓ |
| Input current: | Max. 20.5A |
| Output Voltage: | 4x(12-48)V⎓ |
| Output Current: | 2x(4CHx2.5A) Max.20A |
| Output Power: | 4CHx(0-60...240)W Max. 960W |
| Working Temp.: | -20°C~50°C |
| Dimensions: | L164xW70xH36mm |
| Package Size: | L230xW95xH47mm |
| Weight(G.W.): | 670g |
| Waterproof rating: | IP67 |
| Protection: | Short-circuit, over-temperature and over-current protection with automatic reset capability |
| Input signal: | 0-10V, 1-10V, 10V PWM or push button |
| Input voltage: | 12-24Vdc |
| Max load current: | 12A ×1CH Max 12A |
| Max output power: | 0-144W...288W |
| Dimming Range: | 0~100%, LED start at 0.1% possible. |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | L112×W35×H67(mm) |
| Package Size: | L114×W37×H70(mm) |
| Weight(G.W.): | 125g |
| Input signal: | 0-10V, 1-10V, 10V PWM, push button |
| Input voltage: | 12-24Vdc |
| Max load current: | 5A ×4CH Max 20A |
| Max output power: | 0-240W...480W |
| Dimming Range: | 0~100%, LED start at 0.1% possible. |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | L175×W44×H30(mm) |
| Package Size: | L178×W48×H33(mm) |
| Weight(G.W.): | 150g |
| Input signal: | 0-10V, 1-10V, 10V PWM or push button |
| Input voltage: | 12-24Vdc |
| Max load current: | 12A ×1CH Max 12A |
| Max output power: | 144W/288W(12V/24V) |
| Dimming Range: | 0~100% |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | L175×W44×H30(mm) |
| Package Size: | L178×W48×H33(mm) |
| Weight(G.W.): | 130g |
| Input signal: | 0-10V 1－10V 10V PWM or push button |
| Input voltage: | 12-24Vdc |
| Max load current: | 6A ×1CH Max 6A |
| Max output power: | 72W/144W(12V/24V) |
| Dimming Range: | 0~100% |
| Working Temp.: | -30℃~55℃ |
| Dimensions: | L135×W30×H20(mm) |
| Package Size: | L140×W34×H23(mm) |
| Weight(G.W.): | 65g |
