The LTECH Matter controller series includes 1-channel, 2-channel, and 5-channel models. It also features LTECH’s NFC programmable technology, allowing parameters such as on/off fade time, dimming fade time, brightness range, power-on state, and PWM frequency to be set via a mobile app, making multi-device setup effortless.
| Input Signal: | Matter over Thread |
| Channels: | 5CH |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | RGB Max.15A 5A/CH CW Max.10A |
| Load Power: | 180W@12V 360W@24V 540W@36V 720W@48V |
| Service Life: | 100000 Hours |
| Supported Platform: | Apple Home, Google Home, Amazon Alexa, Amazon Alexa, SmartThings All smart home platforms supporting the standard Matter protocol. |
| Working environment: | -25°C~50°C |
| Product size: | L91×W37×H21(mm) |
| Product weight: | 46g |
| Input Signal: | Matter over Thread |
| Channels: | 2CH |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | 10A/CH@12V 10A/CH@24V 9A/CH@36V 9A/CH@48V |
| Load Power: | 120W@12V 240W@24V 324W@36V 432W@48V |
| Service Life: | 100000 Hours |
| Supported Platform: | Apple Home, Google Home, Amazon Alexa, Amazon Alexa, SmartThings All smart home platforms supporting the standard Matter protocol. |
| Working environment: | -25°C~50°C |
| Product size: | L91×W37×H21(mm) |
| Product weight: | 46g |
| Input Signal: | Matter over Thread |
| Channels: | 1CH |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | 10A@12V 10A@24V 10A@36V 10A@48V |
| Load Power: | 120W@12V 240W@24V 360W@36V 480W@48V |
| Service Life: | 100000 Hours |
| Supported Platform: | Apple Home, Google Home, Amazon Alexa, Amazon Alexa, SmartThings All smart home platforms supporting the standard Matter protocol. |
| Working environment: | -25°C~50°C |
| Product size: | L91×W37×H21(mm) |
| Product weight: | 46g |
| Wireless type: | Matter over Thread |
| Switch channel: | 1CH |
| Operating voltage: | 100-240V~,50/60Hz,μ |
| Load parameters: | Resistive load: 1000W@230Vac, 500W@110Vac, Capacitive load: 400W@230Vac, 200W@110Vac |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 38g |
| Wireless type: | Matter over Thread |
| Switch channel: | 2CH |
| Operating voltage: | 100-240V~,50/60Hz,μ |
| Max. load current of the relay: | 10A |
| Load parameters: | Resistive load: 1000W@230Vac/CH, 500W@110Vac/CH, Max.2000W Capacitive load: 400W@230Vac/CH, 200W@110Vac/CH, Max.800W |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 42g |
![[field:title/]](/images/pdf.jpg "NFC programmable RGBCW Matter LED Controller MA-C5 Manual"){kind=small}
