With over 20 years of deep expertise in smart lighting control, LTECH has built a strong technological foundation. It took the lead in developing the Matter series of smart lighting control products. The LTECH Matter controller enables multi-ecosystem interconnection via the Matter protocol, delivering versatile lighting solutions. It is compatible with major smart home platforms including Apple Home, Google Home, Amazon Alexa, and Samsung SmartThings, and also supports voice control.
| Input Signal: | Matter over Thread |
| Channels: | 5CH |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | RGB Max.15A 5A/CH CW Max.10A |
| Load Power: | 180W@12V 360W@24V 540W@36V 720W@48V |
| Service Life: | 100000 Hours |
| Supported Platform: | Apple Home, Google Home, Amazon Alexa, Amazon Alexa, SmartThings All smart home platforms supporting the standard Matter protocol. |
| Working environment: | -25°C~50°C |
| Product size: | L91×W37×H21(mm) |
| Product weight: | 46g |
| Input Signal: | Matter over Thread |
| Channels: | 2CH |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | 10A/CH@12V 10A/CH@24V 9A/CH@36V 9A/CH@48V |
| Load Power: | 120W@12V 240W@24V 324W@36V 432W@48V |
| Service Life: | 100000 Hours |
| Supported Platform: | Apple Home, Google Home, Amazon Alexa, Amazon Alexa, SmartThings All smart home platforms supporting the standard Matter protocol. |
| Working environment: | -25°C~50°C |
| Product size: | L91×W37×H21(mm) |
| Product weight: | 46g |
| Input Signal: | Matter over Thread |
| Channels: | 1CH |
| Input Voltage: | 12-48V |
| Output Voltage: | 12-48V |
| Load Current: | 10A@12V 10A@24V 10A@36V 10A@48V |
| Load Power: | 120W@12V 240W@24V 360W@36V 480W@48V |
| Service Life: | 100000 Hours |
| Supported Platform: | Apple Home, Google Home, Amazon Alexa, Amazon Alexa, SmartThings All smart home platforms supporting the standard Matter protocol. |
| Working environment: | -25°C~50°C |
| Product size: | L91×W37×H21(mm) |
| Product weight: | 46g |
| Wireless type: | Matter over Thread |
| Switch channel: | 1CH |
| Operating voltage: | 100-240V~,50/60Hz,μ |
| Load parameters: | Resistive load: 1000W@230Vac, 500W@110Vac, Capacitive load: 400W@230Vac, 200W@110Vac |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 38g |
| Wireless type: | Matter over Thread |
| Switch channel: | 2CH |
| Operating voltage: | 100-240V~,50/60Hz,μ |
| Max. load current of the relay: | 10A |
| Load parameters: | Resistive load: 1000W@230Vac/CH, 500W@110Vac/CH, Max.2000W Capacitive load: 400W@230Vac/CH, 200W@110Vac/CH, Max.800W |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 42g |
