North American UL Certified! The K-Series Smart Control Modules fit European, US, and Chinese Standard 86 junction boxes. Compactly designed to fit right inside the junction box, they instantly convert traditional and momentary switches into smart devices!
Supporting diverse protocols and ecosystems including Bluetooth, Matter, DALI, 0-10V, Triac (Phase-Cut), PUSH DIM, and Relay ON/OFF, making smart upgrades more efficient and cost-effective.
| Wireless type: | Matter over Thread |
| Switch channel: | 1CH |
| Operating voltage: | 100-240V~,50/60Hz,μ |
| Load parameters: | Resistive load: 1000W@230Vac, 500W@110Vac, Capacitive load: 400W@230Vac, 200W@110Vac |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 38g |
| Wireless type: | Matter over Thread |
| Switch channel: | 2CH |
| Operating voltage: | 100-240V~,50/60Hz,μ |
| Max. load current of the relay: | 10A |
| Load parameters: | Resistive load: 1000W@230Vac/CH, 500W@110Vac/CH, Max.2000W Capacitive load: 400W@230Vac/CH, 200W@110Vac/CH, Max.800W |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 42g |
| Wireless type: | Bluetooth 5.2 SIG Mesh |
| Switch channel: | 1CH |
| Operating voltage: | 100-240V~,50/60Hz,μ |
| Load parameters: | Resistive load: 1000W@230Vac, 500W@110Vac, Capacitive load: 400W@230Vac, 200W@110Vac |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Wireless type: | Bluetooth 5.2 SIG Mesh |
| Switch channel: | 2CH |
| Operating voltage: | 100-240V~,50/60Hz,μ |
| Max. load current of the relay: | 10A |
| Load parameters: | Resistive load: 1000W@230Vac/CH, 500W@110Vac/CH, Max.2000W Capacitive load: 400W@230Vac/CH, 200W@110Vac/CH, Max.800W |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Peak current: | 30mA@16V |
| Static current: | 2.5mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | DALI-2 |
| Output Method: | Relay |
| Load parameters: | Resistiveload: 800W@230Vac,400W@110Vac，200W@48Vdc; Capacitive load: 300w@230Vac, 150W@110Vac，100W@48Vdc |
| Switch maximum voltage: | AC: 250V，DC: 48V |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Peak current: | 70mA@16V |
| Static current: | 5mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | DALI-2 |
| Output signal: | 0/1-10V×2CH，Max.15mA |
| Load parameters: | Resistive load: 800W@230Vac，400W@110Vac，200W@48Vdc Capacitive load: 300W@230Vac，150W@110Vac，100W@48Vdc |
| Switch maximum voltage: | Max.250Vac，Max.48Vdc |
| Relay surge current: | 70A@10ms |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Interface protocols: | DALI-2 DT6 |
| Operating voltage: | 100-240V~,50/60Hz |
| Input signal: | DALI |
| Output signal: | Triac/ELV |
| Load parameters: | Incandescent lamps or high-pressure halogen lamps: Max.400W@220Vac, Max.200W@110Vac. Dimmable LEDs: Max.200W@220Vac, Max.100W@110Vac |
| Load inrush current: | Max.60A |
| Working environment: | -20°C~50°C |
| Product size: | L45xW20.5xH45.5(mm) |
| Package size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
| Current consumption: | ≤2mA@16V |
| Power supply mode: | DALI Bus power supply |
| Input signal: | Dry contact |
| Output signal: | DALI |
| Working environment: | -25°C~50°C |
| Product size: | L45xW20.5xH45.5(mm) |
| Package size: | L50xW28xH50(mm) |
| Product weight: | 30g |
| Input voltage: | 100-240V~,50/60Hz |
| Input signal: | PUSH DIM |
| Output signal: | 0-10V, MAX.15mA |
| Working environment: | -25°C~50°C |
| Product size: | L45xW45.5xH20.5(mm) |
| Product weight: | 30g |
